25m3/hour Mini Small Portable Precast Ready Mix Mobile Concrete Batching Plant for Sale
Premium 25m3/h mini mobile concrete batching plant engineered for on-site precast and ready-mix production. Features an integrated portable chassis, heavy-duty JS500 twin-shaft mixer, PLD800 batcher, and automated PLC weighing control. Factory Direct Pricing.
Model Code: WADJAY HZS25 Mobile Concrete Plant
Theoretical Capacity: 25 cubic meters per hour (m³/h)
Total Installation Power: 50.25 kW
Main Mixer Configuration: JS500 Compulsory Twin-Shaft
Aggregate Batcher Model: PLD800
Total Equipment Weight: 4,000 kg (4 Tons)
Equipment Packaging Dimensions: 305 x 230 x 268 cm
Highly Uniform Concrete Output: Equipped with an industrial JS500 compulsory twin-shaft mixer that ensures 100% computerized, homogeneous blending of aggregate, cement, and water.
Mobile Towing Chassis Design: Engineered with a durable heavy-duty wheel axle assembly, enabling fast transit between different building project sites with standard truck towing.
High-Precision Electronic Weighing: Features premium load cells delivering strict accuracy control (±1% for cement/water/additives, ±2% for raw aggregates) to comply with international architectural mix design standards.
Automatic Multi-Bin Material Batching: Automatically doses sand, gravel, and stone crushed materials according to predetermined formulas via the PLD800 module.
Synchronized Liquid Weighing & Injection: Digitally weighs water and chemical additives before forcefully injecting them under pressure into the mixer core to eliminate cement balling.
Full-Cycle Automation Operation: Manages aggregate feeding, core mixing, material discharging, and real-time printing via a centralized industrial smart computer cabinet.
Bolted Type or Flaked Type Cement Silo Attachment Upgrade (50-Ton to 200-Ton capacity).
Mobile Wet Batching / Dry Batching custom operational modes.
Custom Electricity Frequency layout (220V/380V/440V, 50Hz/60Hz).
This portable ready-mix manufacturing plant is optimized for small-to-medium infrastructure setups including:
Rural and urban road construction, bridge building, and remote mountain highway projects.
On-site precast concrete component factories, drainage pipe workshops, and localized construction foundations.
